SHUANSHENG SSF-520-S servo injection molding machine
No. 118290
- Type of offer:
- Selling
- Price:
- ~22 055 EUR / pc
- Available quantity:
- 2 pc
- Condition:
- New
- Year:
- 2020
- Manufacturer:
- Others
- Clamping force [kN]:
- 520
- Total power installed [kW]:
- 12.2
- Valid for:
- 8 days
-
- User:
- technikplast
- Company:
- Technikplast Michał Wiśniewski
- Name and surname:
- Michał Wiśniewski
- Contact:
New SHUANSHENG injection molding machine with a clamping force of 520 kN.
Model: SSF-520
Screw diameter: 32 mm
Shot weight: 84 g
L/D ratio: 17.7
Injection pressure: 162 bar
Injection capacity: 65 g/s
Screw speed: 200 rpm
Hydraulic ejector
Hydraulic core
Pneumatic ejector: 4 pcs., fully programmable
Clamping force: 520 kN
Opening stroke: 270 mm
Distance between tie bars: 300 x 300 mm
Minimum mold height: 100 mm
Maximum mold height: 340 mm
Ejector force: 25 kN
Ejector stroke: 75 mm
Motor power: 7.5 kW
Machine dimensions: 3.3 x 1.1 x 1.6 m
Maximum system pressure: 140 bar
Heater power: 4.7 kW
Oil quantity: 115 l
Weight: 2.2 t
